AL225 Axis Inside Wheelchair and Scooter Lift
The 3 Axis lift can transport the largest mobility scooters and power chairs and offers powered lifting, boom extension, and rotation.
- Choose from 4 different models
- Includes a weather-resistant hand control
- Features manual or powered rotation with lockout pin
- Delivers to the side of the vehicle using an integrated, offset post
- Extremely adjustable base and arm height with adjustable boom strap
Indoor Axis Scooter and Wheelchair Lifts can be purchased with one, two, or three motors that operate on their own axes. Each of the 4 available inside lift models mount in the cargo space of the vehicle. An offset base position allows the mobility device to be safely loaded and unloaded on the side of the vehicle.
The Single Axis scooter uses one motor that lifts and lowers the scooter or power chair but rotates manually to rotate the mobility device into the vehicle's trunk, where the lift is mounted.
The Double Axis lift uses two motors to provide both power lift and rotation for transporting lighter power chairs and scooters. A Premium 2 Axis Lift has a 400 lb. weight capacity and works well for larger vehicles. The 3 Axis lift can transport the largest mobility scooters and power chairs and offers powered lifting, boom extension, and rotation.
All Indoor Axis Scooter and Wheelchair Lifts come with a weatherproof hand control. Customize your mobility accessory lift with a wireless controller, a Lightweight Battery Pack, or Base Adapters.
Product Specifications / Dimensions
| Axis I / Single Axis Inside Lift AL215 | |
| Included Accessories | Docking Device and Universal Base Adapter |
| Lifting Capacity | 250 lbs. (113 kg) |
| Operation | Power lifting w/ Manual Rotation |
| Adj. Boom Height | 30" - 40" |
| Adj. Lifting Strap Length | 22" - 34" |
| Boom Pitch | 5 degrees |
| Adj. Rotation Limit | Yes |
| Warranty | 3 Year Transferrable |
| Installed Weight | 42 lbs. |
| Axis II / 2-Axis Inside Lift AL225 | |
| Included Accessories | Docking Device and Universal Base Adapter |
| Lifting Capacity | 250 lbs. (113 kg) |
| Operation | Power Lifting and Rotation |
| Adj. Boom Height | 30" - 40" |
| Adj. Boom Strap Length | 22" - 34" |
| Boom Pitch | 5 degrees |
| Warranty | 3-Year Transferrable |
| Installed Weight | 55 lbs. |
| Axis II / 2 Axis Premium Inside Lift AL425 | |
| Included Accessories | Docking Device and Universal Base Adapter |
| Lifting Capacity | 400 lbs. (181 kg) |
| Operation | Power lifting and rotation |
| Adj. Boom Height | 30" - 41" |
| Adj. Boom Length | 23.5" - 33.5" |
| Adj. Boom Pitch | 0 - 30 degrees |
| Adj. Rotation Limit | Yes |
| Warranty | 3 year transferable |
| Installed Weight | 66 lbs. |
| Axis III / 3-Axis Inside Lift AL435 | |
| Included Accessories | Docking Device and Universal Base Adapter |
| Maximum Lifting Capacity | 400 lbs. |
| Installed Weight | 76 lbs. |
| Maximum Lifting Height | 43" at Horizontal Boom Position |
| Minimum Lifting Height | 32" at Horizontal Boom Position |
| Range of Boom Adjustment | Powered from 21" - 31.8" |
| Arm Angle Adjustment | -31.5 to 40.5 degrees (5 deg increments) |
| Column Rotation | 180 degree adj. at +/- 20 degree increments |
