EV Rider MiniRider Lite 4-Wheel Mobility Scooter
EV Rider MiniRider Lite
Product Code: MiniRider
$1,155.00
Description
EV Rider MiniRider Lite 4-Wheel Mobility Scooter
MiniRider Lite is a transportable scooter with the stability of a 4-wheel scooter and the turning radius of a 3-wheeler, providing the customer greater maneuverability.
The MiniRider Lite is a transportable scooter with the stability of a 4-wheel scooter and the turning radius of a 3-wheeler, providing you with greater maneuverability. With a 280 lb. load capacity and 4 wheels, the MiniRider Lite can transport heavier individuals with stability. The folding mobility seat has comfortable cushions and armrests that flip up and/or can be adjusted laterally.
Features
- Includes scooter, basket, 12Ah battery pack and charger
- Tight turning radius
- Flip-up arm rests
- Padded swivel seat
- Easy assembly/disassembly
- Maximum speed 4 mph
- Up to nine miles per charge
Technical Specs
Details and Specifications for the EV Rider MiniRider Lite
| Length | 42.5" |
| Width | 19" |
| Height | 36" |
| Front section | 35 lbs |
| Rear section | 26 lbs |
| Battery pack | 20 lbs |
| Seat | 16 lbs |
| Weight with batteries | 92 lbs |
| without battery | 72 lbs |
| Battery | 12 AH (option 18AH) |
| Charger | 2A Off-Board |
| Tire Size | 8" x 2" |
| Front Tire | 200X50 PU TIRE |
| Rear tire | 200X50 PU TIRE |
| Ground clearance | 3" |
| Seat height | 23" |
| Seat height "“ cushion to deck | 20" |
| Seat | Fish on seat |
| Seat width | 17" |
| Seat depth | 16" |
| Top Speed | 4 mph |
| Battery range 12V 12AH SLA Battery | Up to 10 miles |
| Battery range 12V 18AH SLA Battery | Up to 18 miles |
| Turning radius | 52" |
| Wheelbase | 31" |
| Climbing angle | 8 degrees |
| Motor size | 270 Watts |
| Max. user weight | 280 lbs |
| Controller | Curtis 45A |
| Colors | Red, Green, Silver, Blue |
(*) SPECIFICATION PERFORMANCE IS DETERMINED IN THE LABORATORY SETTING BASED ON IDEAL CONDITIONS (MINIMAL FRICTION, NO WIND AND CONTROLLED TEMPERATURE AND PRESSURE WITH AN
Wheelchair Measuring Guide
Wheelchair Measuring Guide
Wheelchair Measurements:
- Hip Width:
Use this to figure seat width if it is the widest point. - Widest Point:
Measure the widest area across the lower extremities if different from the hip width. This may influence seat width or arm style. - Chest Width:
Measure the widest point of the thorax just below the armpit. This measurement may influence system width or back width. - Heel to Knee:
Use this for legrest extensions and seat height. - SRP to Knee (Seat Reference Point to Knee):
This will determine the seat depth. - Elbow to SRP (Elbow to Seat Reference Point):
Measure this width with the arm in a 90-degree angle at the elbow and the shoulder in a neutral position. - Shoulder Height:
This will determine the height and the style of the back panel or the start for a custom back. - Head Height:
This will help determine the proper headrest height.
