Karman Healthcare Tilt in Space Reclining Transport Wheelchairs
Product BrochureProduct Code: VIP2TR
Karman Healthcare Tilt in Space Reclining Transport Wheelchairs
The Karman VIP2 Tilt-in-Space & Reclining Transport Wheelchair is the next generation in innovation and design for Tilt wheelchairs. The VIP2 series is a revolutionary tilt and recline transport wheelchair that weighs just 36 pounds in transport mode. This design of wheelchair may be optimal for users who require a higher degree of pressure relief compared to your manual wheelchair.
The tilt and recline design allows for the user weight to be more evenly distributed on the entire body versus a standard wheelchair that can cause an immense load of pressure on the lower back, which can then lead to pressure sores, skin breakdown, and further complications. A tilt range of 0-35 º is crucial in our weight-shifting center-of-gravity pressure relief design, coupled with the 30 º range of reclining back, and an aircraft grade T6 aluminum frame.
Features :
- Weighs only 43 lbs (without footrest)
- Tilt in Space and Reclining Function
- Intelligent 0-35 º degree tilt evenly distributes pressure
- Reclining Backrest range of 0-30 º
- Globally Patented Folding Design
- Breathable Seat and Back Sling
- Aegis Anti-Bacterial Seat, Back, and Head Cushions
- Removable Armrest Assembly with Height Adjustable Desk Arm Pads
- Removable Footrest with Heel Loop
- Tension Adjustable Backrest
- Pelvic Seat Belt Included
- Companion Brakes and Companion Tilt-Recline Operated
- 14" x 1" Polyurethane High Tread Flat Free Rear Wheels
- 7" x 1" Polyurethane Front Casters
- Frame Color: Diamond Black
- Upgraded To Elevating Legrest
- Weight Capacity of 255 lbs.
Product Specifications:
- Seat Width : 16" or 18" options
- Seat Depth : 18 inch.
- Armrest Height : 8-11 inch.
- Seat Height : 19 inch.
- Back Height : 19 inch. + (16 inch. adj. headrest)
- Overall Height : 40-56 inch.
- Overall Open Width : 27 inch.
- Folded Width : 16 inch.
- Overall Length : 44 inch.
- Weight Without Riggings/Footrest : 43 lbs.
- Weight Capacity : 255 lbs.
- Shipping Dimensions : 35" L x 33" H x 16" W
Product Specifications / Dimensions
| 16-inch Model | 18-inch Model | |
| Weight Capacity | 255 lbs | 255 lbs |
| Seat Dimensions | 16"W x 18"D | 18"W x 18"D |
| Armrest Height | Adjustable, 8"-11" | Adjustable, 8"-11" |
| Floor to Seat Height | 19" | 19" |
| Back Height | 19" without Headrest, 37" with Headrest | 19" without Headrest, 37" with Headrest |
| Overall Height | 40" without Headrest, 56" with Headrest | 40" without Headrest, 56" with Headrest |
| Overall Open Width | 25" | 27" |
| Folded Width | 16" | 16" |
| Overall Length | 44" | 44" |
| Front Caster Size | 7" | 7" |
| Rear Caster Size | 14" | 14" |
| Product Weight (without Riggings) | 43 lbs | 43 lbs |
Wheelchair Measuring Guide
Wheelchair Measurements:
- Hip Width:
Use this to figure seat width if it is the widest point. - Widest Point:
Measure the widest area across the lower extremities if different from the hip width. This may influence seat width or arm style. - Chest Width:
Measure the widest point of the thorax just below the armpit. This measurement may influence system width or back width. - Heel to Knee:
Use this for legrest extensions and seat height. - SRP to Knee (Seat Reference Point to Knee):
This will determine the seat depth. - Elbow to SRP (Elbow to Seat Reference Point):
Measure this width with the arm in a 90-degree angle at the elbow and the shoulder in a neutral position. - Shoulder Height:
This will determine the height and the style of the back panel or the start for a custom back. - Head Height:
This will help determine the proper headrest height.
