EV Rider City Cruzer Mobilty Scooter
  • EV Rider City Cruzer Mobilty Scooter
  • EV Rider City Cruzer Mobilty Scooter
  • EV Rider City Cruzer Mobilty Scooter
  • EV Rider City Cruzer Mobilty Scooter
  • EV Rider City Cruzer Mobilty Scooter
EV Rider City Cruzer Mobilty Scooter

EV Rider City Cruzer Mobilty Scooter

EV Rider City Cruzer 4 Wheel Mobilty Scooter
  • A 4-Wheel scooter with 3-wheel turning radius
  • Only small scooter with rear true mono-shock suspension
  • 300 lb weight capacity

Product Code: WT-T4SC

$1,540.00
Image 1
Image 2
Description

EV Rider City Cruzer 4 Wheel Mobilty Scooter

The CityCruzer scooter is a transportable scooter on the market with full suspension. The CityCruzer has the stability of a four (4) wheel scooter with the turning radius of a three (3) wheeler, providing the customer greater maneuverability. It is the only small, disassembling scooter available with a mono-shock suspension and a standard size (not mini) transaxle.

With a 285 lb load capacity and 4 wheels, the CityCruzer can transport higher weight individuals with a stability not usually found in portable scooters. The folding mobility seat has deep cushions and armrests that flip up and/or can be adjusted laterally.

FEATURES:
  • A 4-Wheel scooter with 3-wheel turning radius
  • Only small scooter with rear true mono-shock suspension
  • 300 lb weight capacity
  • Heaviest piece is only 45 Pounds
  • 8" x 2" flat free/solid alloy wheels
  • 13 Mile Range
  • Max Speed 4 MPH
  • Disassembles in seconds for easy hand-carry and storage
Ev Rider City Rider
Technical Specs

SPECIFICATIONS:

  • Dimension (L x W x H) in mm: 1080 x 495 x 940 mm
  • Dimension (L x W x H) in inches: 42.5 x 19.5 x 37 Inches
  • Ground Clearance: 3"
  • Weight with Battery: 57.5 kg /126.7 lbs
  • Weight Without Battery: 44 kg / 96.8 lbs
  • Battery: 20 mAh
  • Controller: Dynamic 50A
  • Charger: Input AC 100-240 V, Output 24 V, 1.5 Amp
  • Front Wheel Size: 200 x 50 mm / 8" x 2"
  • Rear Wheel Size: 200 x 50 mm / 8" x 2"
  • Driving System: Direct drive the rear wheel
  • Brake System: Electromagnetic brakes
  • Control Method: By speed control lever
  • Max Speed Forward: 6.4 kph / 4 mph
  • Slop Grade Ability: 8°
  • Cruising Range: 16-20 km / 10-13 mile
  • Max Loading: 136 kg / 300 lbs
  • Battery Weight: 13.6 kg
  • Seat Weight: 11.5 kg
  • Minimum turning radius: 53"
  • Turn-around width between limiting wal: 55.12"

Warranty:

  • 3 Year Limited Warranty - All structural frame components - platform, seat post and frame
  • 1 Year Limited Warranty - Electrical component of scooter or Charger. It will be replaced without charge. Labor is not included.
  • 6 month Limited Warranty - All Spare parts
Wheelchair Measuring Guide

Wheelchair Measuring Guide

Wheelchair Measuring Guide Wheelchair Measuring Guide

Wheelchair Measurements:

  1. Hip Width:
    Use this to figure seat width if it is the widest point.
  2. Widest Point:
    Measure the widest area across the lower extremities if different from the hip width. This may influence seat width or arm style.
  3. Chest Width:
    Measure the widest point of the thorax just below the armpit. This measurement may influence system width or back width.
  4. Heel to Knee:
    Use this for legrest extensions and seat height.
  5. SRP to Knee (Seat Reference Point to Knee):
    This will determine the seat depth.
  6. Elbow to SRP (Elbow to Seat Reference Point):
    Measure this width with the arm in a 90-degree angle at the elbow and the shoulder in a neutral position.
  7. Shoulder Height:
    This will determine the height and the style of the back panel or the start for a custom back.
  8. Head Height:
    This will help determine the proper headrest height.


Printable Wheelchair Measurement Guide
